LPA-12N series LED constant current waterproof power supply
Features：·Constant current style power supply
·160～264VAC AC input
·Small volume，low weight，high efficiency
·Protections：short circuit/over load
·Cooling by free air convection
·Fully encapsulated with IP67 level
·100% full load burn-in test
·1 Year warranty
|
Model |
LPA-12N-1000 |
LPA-12N-700 |
LPA-12N-350 | |
|
output |
DC voltage |
1000mA |
700mA |
350mA |
|
Voltage tolerance |
7~12V |
10~17V |
20~34V | |
|
Rated current |
12W |
11.9W |
11.9W | |
|
Current range |
200mvp-p |
200mvp-p |
200mvp-p | |
|
Rated power |
±5% |
±5% |
±5% | |
|
Ripple&noise |
±2% |
±2% |
±2% | |
|
input |
Voltage range |
160~264VAC，230~370VDC | ||
|
Frequency |
47~63HZ | |||
|
AC current |
0.15A/230VAC | |||
|
Efficiency |
82% | |||
|
Inrush current |
Cold start current 30A/230VAC | |||
|
Leakage current |
<0.5mA/240VAC | |||
|
protection |
Over load |
±5%Rated current | ||
|
Protection type：rated current limit | ||||
|
----- |
----- | |||
|
----- | ||||
|
environment |
Workingtemp,humidity |
-10℃~+60℃，20%~90%RH | ||
|
Storage temp.humidity |
-20℃~+85℃，10%~95%RH non condensing | |||
|
Withstand vibration |
10~500HZ，2G 10min/1cycle，period for 60minutes，each axes | |||
|
safety |
Withstand voltage |
I/P-O/P：1.5KVAC | ||
|
Isolated resistance |
I/P-O/P：100M ohms/500VDC | |||
|
Fits tandard |
Safety standard |
Fit UL1012，IP67 protect level | ||
|
EMC standard |
Fit EN55022，CLASSA | |||
|
Others |
Dimension |
128*32*22mm (L*W*H) | ||
|
Weight/packing |
0.15kg/100pcs/16kg/0.027m³/0.94CUFT | |||
|
Note |
1. All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25℃ of ambient temperature. 2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor. 3. Tolerance : includes set up tolerance, line regulation and load regulation. | |||
